PM1122-INT DIGITAL INTERFACE REMOTE

WWW.APART-AUDIO.COM / INFO@APART-AUDIO.COM

Overview

ThePM1122Pre‐ampcanberemotecontrolledbythePM1122‐INT.ThePM1122‐INTcanbe

controlledin3differentways:

• UsingRS‐232

• Usingthecontactstorecallpresets

• UsingtheoptionalRFmodule

ForcontrolusingtheRS‐232port,thePM1122‐INTacceptsstringsofASCIIcharacterstocontroland

readsettingsofmusiclevel,microphonemixleveland theinputselectorofbothzones.Further,the

RS‐232portwillhavetobeusedtostorepresets,adjustminimumandmaximumlevelsettings.

Stringscanbesentviathird‐partysoftwarelikeHilgraeve’sHyperterminalorthefreewareutility

“HerculesSETUPutility”fromHW‐group.



Forpresetcontrolusingcontacts,it’sneededtostore thepresetsusingRS‐232.Itcanbedoneusing

terminalsoftware(Hyperterminal,Hercules,...)orwiththeAPartPM1122ControlPanelsoftware.

PleasenotetheAPartsoftwarerunsonlyonWindows®platforms,it’sfreelydownloadablebutno

supportorguarantiesaregiven.

Oncethepresetsarestored,noRS‐232communicationisneededanymore.Refertothechapter

Presetsformoreinformation.



ForcontrolusingtheoptionalRFmodule,noconfigurationwithRS‐232isneeded.Oncethemodule

ismounted(seechapter“

Easywave”onpage9),thepushbuttonsatthefrontsideareenoughto

assignaswitchtoazone.PleasenotetherearesomefeatureswhichcanbeconfiguredusingRS‐232

butfornormaloperation,it’snotneeded!

PM1122INTfrontpaneldescription



67891011



1. Clearwirelessremotesknob

2. Wirelessremotelearnbuttonforzone1

3. Learnledforzone1

4. Wirelessremotelearnbuttonforzone2

5. Learnledforzone2

Atpowerup,LEDbar11will

showthecurrentbaudrate.See

aboveforthepossiblevalues.

12345

19200

9600

4800

2400

6. Musicselectorindicatorforzone1

7. Musiclevelindicatorforzone1.

Note:buttons1,2and4havebeen

mountedslightlyrecessedtoavoid

unintendedoperation.Ifnecessary,

useapenorpenciltopushthese

buttons.

8. Microphonemixlevelindicatorforzone1

9. Musicselectorindicatorforzone2

10. Musiclevelindicatorforzone2

11. Microphonemixlevelindicatorforzone2


