RecallapresetusingRS‐232

RecallingapresetwithRS‐232canbedonewiththeRCLcommand.Thiswillchangethevaluesto
thoseofthecorrespondingmemorylocation.Againafewexamples:
Torecallthesettingsasstoredinpreset2(ifthepresetwasstoredforbothzones,thenthestored
settingswillbeappliedtoBOTHzones):
 RCLPRESET2<CR>
Toputthelevelsofzone2totheminimumandsourceofzone2to“A”:
 RCLPRESETZONE20<CR>
Torecallpresetnumber1settingstozone1only(evenifthepresethasbeenstoredasazone1and
2preset):
 RCLPRESETZONE11<CR>

PM1122ControlPanelSoftware

InordertotestanddemonstratemostofthePM1122‐INTfeatures,acustomapplicationcalled
PM1122ControlPanelwasdeveloped.Thissoftwaretoolrunsonlyonwindows®platforms.It’s
offeredfordidacticaluse.Itcanbeveryhandytocreateandstorepresets.Pleasenotethesoftware
isofferedforfreebutthereisnoguaranteeitwillworkoneveryplatformandnosupportisgiven.If
theprogramisnotworkingonyourplatform,pleaseuseterminalsoftware.Pleaserefertochapter
“
ControllingthePM1122‐INTwithHercules”atpage19tolearnmoreaboutourrecommended
andincludedalternative.
YouwillneedacomputerrunningWindows2000/XP/vistawitha9pinRS‐232COMconnectoranda
standardstraightthroughserialcable.Ifnoserialportisavailableonyourcomputer,youcanusea
USBtoserialconverter.It’srecommendedtoinstalltheUSBtoserialconverterdriversbefore
installingthePM1122ControlPanelsoftware.
Thesetupforthe“PM1122ControlPanel”softwarecanbefoundontheincludedCDbutifyouhave
internetaccess,pleasecheckthewebsiteforthelatestversion.AllPM1122relatedinformationand
documentationcanbefoundathttp://www.apart‐audio.com

Tosetuptheprogram,starttheinstallationprogramandfollowtheinstructionsasshownonthe
screen.Youwillneedsufficientuserrightsonyourcomputerinordertoinstallandruntheprogram,
sopleaseaskyoursystemadministratorforassistanceifnecessary.
Whenthesoftwareisinstalledsuccessfully,connectthePM1122‐INTtoyourcomputerandstartthe
application.Ifyouhavenotassignedashortcuttotheapplication,double clickthePM1122.exefile
foundinthestandardinstallationdirectory:
C:\ProgramFiles\Audioprof\PM1122ControlPanel\PM1122.exe
Thefirstscreenyouwillseeshouldlooklikethis:


