InstructionsetPM1122INT

ThePM1122‐INTcanbeco ntrolledusingRS‐232.Duringpowerup,thecurrentbaudrateisshownon
aLEDbar.Pleasereferto“
PM1122‐INTfrontpaneldescription”atpage3forthecorresponding 
values.
Initialportsettingsare19200bitspersecond,8databits,noparity,1stopbitandnoflowcontrol.
Onlythebaudratecanbeconfiguredatdifferentvalues.

StandardASCIIstringsareusedtocontrolthePM1122‐INTsoit’spossibletouseTerminalsoftware
(e.g.HyperTerminal,Hercules,...)totest,configureand/orcontrolit.Instructionsarenotcase
sensitive.EachstringmustbeendedwithaCarriageReturn(<CR>,ASCIIcode13or”\n”)

Thestringisstructuredinthefollowingorder:
CommandAttributeParameter1Value<CR>
Stringsrequireaspacebetweeneachparameter;thelastcharacterinthestringneedstobea
carriagereturn<CR>.Linefeed<LF>charactersareignoredsotheymaybeused.

Aninstructionconsistsofacommand,anattributeandpossibleoneoremoreparameters.E.g.the
instructiontoswitchthemusicvolumefromzone1atmaximumwilllooklikethis:
SETMSCLVLZONE1100<CR>
whereSETistheinstruction,MSCLVLtheattribute,ZONE1thefirstparameterand100thesecond
parameterwhichisthevalue.

Commands

Thisisalistofcommandswithabriefdescription

SET Setthevalueofavariable
GET Getthevalueofavariable
RCL RecallaPreset
LRN LearnacodeofEasywaveRFswitch
CLR ClearpresetorEasywaveRFidentificationcodes
HELP ListsCommandsandAttributes
LST ListsCommandsandAttributes(sameasHELP)
STR StoreaPreset
INC Increasethevalueofavariable
DEC Decreasethevalueofavariable

Attributes


Theattributescanbegroupedincontrolsandsettings.Controlswillreally“control”thePM1122
whilesettingsonlydeterminethebehaviourofthePM1122‐INT.
Controls

MSCLVL:  MusicLevel

