APC 10000 VA - USER CONFIGURABLE SETTINGS; Bypass and Output Voltage Settings; Output Frequency and Battery Count Settings

12
NOTE: SETTINGS ARE MADE THROUGH SUPPLIED POWERCHUTE SOFTWARE, SMART SLOT
ACCESSORY CARDS, OR TERMINAL MODE.
FUNCTION
F
ACTORY
DEFAULT
USER SELECTABLE
CHOICES
D
ESCRIPTION
High Bypass Point +10% of
output voltage
setting
+5%, +10%, +15%,
+20%
Maximum voltage that the UPS
will pass to connected
equipment during internal
bypass operation.
Low Bypass Point -30% of output
voltage setting
-15%, -20%, -25%, -30% Minimum voltage that the UPS
will pass to connected
equipment during internal
bypass operation.
Output Voltage 230 VAC 200, 208, 220, 230,
240 VAC
Allows the user to select the
output voltage while on-line.
Output Frequency Automatic
50 ± 3 Hz or
60 ± 3 Hz
Automatic
50 ± 3 Hz
50 ± 0.1 Hz
60 ± 3 Hz
60 ± 0.1 Hz
Sets the allowable UPS output
frequency. Whenever possible,
the output frequency tracks the
input frequency.
Number of Batteries 1 Number of Connected
Batteries
Defines the number of
connected batteries for proper
run time prediction.
Default setting of 1 = 1920 VAh
(192 V x 10 Ah)
Setting of 2 = 3840 VAh, etc.
