APC 1000VA User Manual

3
Mounting the UPS in a Rack
The UPS is heavy. To lighten it, you may remove the battery before mounting the unit in the rack
(Steps 1 and 2).
Install the UPS at or near the bottom of the rack.
Check to make sure the rack will not tip after installing the UPS into the rack.
Step B
Ste
p
A
Step 1
Step 2
Be careful-the battery is heavy.
Step 3
Step 4
Step 5

APC 1000VA Specifications

General

Output Voltage	230V
Input Voltage	230V
Topology	Line Interactive
Waveform	Stepped approximation to a sinewave
Output Power	600W
Input Frequency	50/60Hz
Output Frequency	50/60Hz
Battery Type	Lead-acid battery
Audible Alarm	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-15°C to 45°C
Humidity	0-95% non-condensing
