2: INSTALLATION

The UPS has a “rack and stack” design that provides two mounting options. The UPS can be

mounted in a 46.5 cm (19-inch) equipment rack or stacked on a battery pack(s) model

SU24RMXLBP2U. Hardware is provided for either option.

UNPACKING

Inspect the UPS upon receipt. APC designed robust packaging for your product. However, accidents

and damage may occur during shipment. Notify the carrier and dealer if there is damage.

The packaging is recyclable; save it for reuse or dispose of it properly.

Check the package contents. The package contains the UPS (with battery disconnected), the front

bezel, and a literature kit containing one CD, one serial cable, and product documentation. The pack-

age will also include a mounting kit with brackets, cleats, feet, and hardware, and a rail kit (necessary

for rack mounting the UPS), containing mounting rails, installation instructions, and a hardware

packet.

230V models have one power cord included with the literature kit.

The UPS is shipped with the battery and the front bezel disconnected. You will connect

the battery and install the bezel during the installation procedure (described later).

POSITIONING THE UPS

Place the rack and the UPS where they will be used for either rack mounting or stacking. (Both pro-

cedures are detailed on the following pages.) The UPS is heavy. Select a location sturdy enough to

handle the weight.

You must install the UPS in a protected area that is free of excessive dust and has adequate airflow.

Ensure the air vents on the front and rear of the UPS are not blocked.

Do not operate the UPS where the temperature and humidity are outside the specified limits. Refer to

Specifications at the APC web site, www.apc.com/support

PLACEMENT

INSTALLING THE SMART-UPS

To install the Smart-UPS, follow these basic steps. Details are provided on the following pages.

1. Stack the UPS on the battery pack or install the mounting rails in the rack (four-post rack instal-

lation only). Place the UPS in the rack. Install the UPS at or near the bottom of the rack.

2. Connect the battery and attach the front bezel.

3. Connect the equipment and power to the UPS.

4. Turn on the UPS.

5. Install optional software and accessories.
