3.0 Presentation
3.1 250VA UPS—front panel
Front-panel indicators
see Sec. 5.1, 5.2.1, 5.2.2
all versions
Site Wiring
Fault light
see Sec. 4.7
Option
switches
see Sec. 5.4
100 & 120 Vac versions
3.2 250VA UPS—rear panel
UPS Enable
switch
Circuit
breaker
IEC 320
power inlet
Test
button
see Sec. 5.2
Computer
Interface port
see Sec. 6.4
Load outlets
NEMA 5-15R
receptacles
220/230/240 Vac version
Load outlets
IEC 320 ouput
coulpers
