4.0 Installation
4.1 Receiving inspection
Once you remove the UPS from its shipping container, inspect it for dam-
age that may have occurred while in transit. Immediately notify the carrier
and place of purchase if any damage is found. The packing materials are
made from recyclable materials and should be saved for reuse or disposed
of properly.
4.2 Placement
You may install the UPS in any protected environment. The location should
provide adequate air flow around the unit, in an atmosphere free from
excessive dust.
Note: Allow 1-inch (2.5 cm) minimum
clearance on all sides for proper
ventilation.
m amF
m "F©
¦Fd p"=
p§ "F©
F
Fzd "4F"F©
ma mF
m"F©
¦Fdp"=
p§"F©
F
Fzd"4F "F©
s |¢Q 4h}
Do not operate the UPS in an environment where the ambient temperature
or humidity is outside the limits given in the Specifications section of this
manual (see Sec. 9.6).
