Smart-UPS Rack-Mount2U 750/1000/1500 VA 120/230 Vac, 3000 VA 100/120/208/230 Vac, 2200 VA 120 Vac 2
Front and Rear Panel Features
Front panel features
Rear panel features
1
Battery
2
Battery connector
3
Display interface
4
Bezel
1
SmartSlot for optional NMC accessory card
2
UPS input
3
Circuit breaker/Overload protection
4
Controlled outlet group
5
Chassis ground screw
6
Outlets
7
EPO connector
8
USB port
9
RJ45 connector - UPS monitoring serial port
750/1000 VA 120 Vac
1500 VA 100/120 Vac 3000 VA 100/120 Vac
750/1000/1500 VA 230 Vac 3000 VA 208 Vac
2200 VA 120 Vac 3000 VA 230 Vac
su0498a
su0644a
su0624a
su0645a
su0625a
su0623a
su0626a
