7Smart-UPS Rack-Mount2U 750/1000/1500 VA 120/230 Vac, 3000 VA 100/120/208/230 Vac, 2200 VA 120 Vac
Advanced menus
The Advanced menus provide additional options for the UPS and are available only if the display interface is
configured to use the Advanced menus.
Menu General Functions
Status
View detailed information about the UPS:
• Energy meter
• Load current
• Status of the Switched Outlet Group
• Battery voltage
• Operation mode
• Efficiency
• SmartSlot Card (if applicable)
Configuration
Configure advanced settings for the UPS:
• Main and Switched Outlet Group—delays and settings
• High and lower transfer points
• Sensitivity settings
• Date of last battery replacement
• Output voltage
• Battery settings
• Number of battery packs (not available on all models)
• Reset energy meter
• UPS test settings
• Display: Always On, Auto Off, Auto Dim
Control
Control the Main and Switched Outlet Group to turn on,
turn off, shutdown, or reboot.
Test & Diags
Perform UPS test and diagnostic functions such as user
interface testing, battery tests, and battery calibration.
Log
View the event and error logs for information about any
changes to the UPS and any faults.
About
View information about the unit:
• Hardware version
• Software version
• NMC information, if applicable
• SmartSlot Card information, if applicable
