106 007-5510-002
5.6.2 Weight
5.6.3 AC INPUT PCM
5.6.4 DC INPUT PCM
Item Quantity per System LBS (kg) Extended Weight
Chassis
Includes
Base PCB & Midplane
18383
PCM 2 12 24
I/O Module Drives 2 4 8
60 2 120
Miscellaneous 1 5 5
Total Weight 240
Input Parameter Value
Input Voltage 190 - 264 VAC
Input Frequency 47 - 63 Hz and 400 hz
Maximum Input Current 13.1A RMS @ 190 VAC
Peak Inrush Current 50A @ 230VAC, 25
0
C, 5 msec max
Minimum Efficiency
measured at 30% and 50%
load and nominal line
(208 VAC)
90%
Maximum Average Output Power 1750 W
Maximum Peak Output Power, 1 second 1922W
Input Parameter Value
Input Voltage 36 - 72 VAC
Maximum Input Current TBD
Peak Inrush Current TBD
Minimum Efficiency
measured at 30% and 50%
load and nominal line
(48 DVC)
90%
Maximum Average Output Power 1750 W
Maximum Peak Output Power, 1 second 1922W
