Vortex M Edition Desk Assembly Guide
4/ Page
HARDWARE LIST
TOOLS REQUIRED
Allen wrench 4mm×1
Allen wrench 5mm×1
Allen wrench 2.5mm×1
Phillips screwdriver
(Not provided)
HARDWARE INCLUDED
M6X20 X9
M6X14 X20
ST3.5X19 X4
Rubber Grommet X8
Cable Clip X4
USAGE
Qty
M6x20
9
M6x14
20
ST3.5x19
4
Rubber Grommet
8
Cable clip
4
Install on support brackets & cross beam
Cable management
Secure controller
Secure top, contol box & support brackets
Secure feet
