example: output level +18 dEu;
18
Ep = Antilog
x 1.1 = 8.74 Vpeak
20
To determine the proper output ceiling
the peak output voltage (Ep) is specified,
equation:
setting in dBu if
use the following
Ep
dBu = 20 x Log -----
1.1
example: required output ceiling = 9 V peak;
9
dBu =
20 x Log
= 18.3 dBu
1.1
Note that the RMS output of
necessarily equal .707 times the peak
because most audio waveforms have a much
amplitude ratio than pure sine waves.
6.3 Secondary Controls
the limiter
output level.
higher peak to
will not
This is
average
The secondary controls on the Studio Dominator and their
functions are as follows:
6.3.1 LF EQ-
Adjusts the relative drive to the low band
limiter.
6.3.2 LF X-OVER-
Selects 80 or 160 Hertz as the low-to-mid
crossover frequency.
6.3.3 HF EQ-
Adjusts the relative drive to the high band
limiter.
6.3.4 HF X-OVER -
Selects 1700 or 4500 Hertz as the mid-to-high
crossover frequency.
6.3.5 PROCESS ON-OFF-
Activates the limiter circuits when "on" and
deactivates limiting when "off". Equalization,
drive, TEe, and output ceiling controls remain
active in both positions.
