APOGEE ELECTRONICS
8
Symphony PCI card – User’s Guide
AD-16X & DA-16X
Interface Connections Chart: Standard Routing
INPUT
OUTPUT
AD-16X #1
INTERFACE SET CHANNELS IN USE
1-16 17-32
From Computer
INPUT
OUTPUT
AD-16X #1
1-16 17-32
From Computer
INPUT
OUTPUT
DA-16X #1
1-16 17-32
From Computer
AD-16X #2
INPUT
OUTPUT
DA-16X #1
1-16 17-32
From Computer
DA-16X #2
T
M
T
M
T
M
T
M
T
M
T
M
The following chart depicts all possible configurations of Apogee interfaces that may be connected per Sym-
phony PCI card. Under “Channels in Use”, the mapping of the interface’s I/O to the Symphony card’s I/O is
indicated.
Please note that AD and DA16X possible configurations change based on the whether units are in Standard or
Advanced Routing.
