16
Adjustments
Push Buttons
Jumpers
TIMER TO CLOSE Adjusts time before gate automatically closes 1-60 seconds.
DUAL GATE DELAY Adjusts delay between master and slave operation 0-4
(836 only) seconds. (for use with magnetic and mechanical locks.
or stop tabs)
CURRENT SENSITIVITY Increases or decreases the Auto Reverse sensitivity.
LED ENABLE When depressed, activates LEDs for 15 minutes to assist in installa
tion and troubleshooting. Holding the button down for five seconds
will put the board in learn mode.
RESET Resets the microprocessor. Returns processor to
last known state.
STOP CIRCUIT JUMPER When the STOP CIRCUIT JUMPER
is connected, the gate will operate normally.
STOP CIRCUIT JUMPER When a 3-button station is connected to
the board, the STOP CIRCUIT JUMPER
must be removed.
