Solarpaint
AL1206 Installation Manual
14.9.2023
Rev. [B1]
Page 15 of 28
3) Using 2 workers, hold the module from both short edges. Attach one edge while the
opposite edge is lifted.
4) Advance slowly to the opposite side whilst pressing gently on the adherence lines until
reaching the opposite side.
e) Module application on Bitumen waterproofing membranes
f) For paste adhesive: Apply a layer of adhesive (6-8mm height) along the prepared surface
while keeping a minimum distance from the module edges (see Example below). The
adhesive should be applied in segmented lines to allow proper curing of the adhesive.
g) Apply two middle adherence lines (Note: To allow the adhesive to cure properly, do not form
a "closed" shape).
