Resistance
Range Resolution Accuracy
400.0Ω
4.000kΩ
40.00kΩ
400.0kΩ
0.1Ω
1Ω
10Ω
100Ω
4.000MΩ
40.00MΩ
400MΩ
4.0GΩ
1kΩ
10kΩ
1MΩ
100MΩ
0.2%+2d
0.2%+1d
1.0%+1d
2.0%+20d
5.0%+20d [1]
5.0%+8d [2]
[1] Above 200MΩ of range, add 10d to accuracy.
[2] Above 2GΩ of range, add 2d to accuracy.
Maximum Open Circuit Voltage : Approx. 2.5V
Maximum Short Test Current : Approx. 0.1mA
Continuity Check
Maximum Open Circuit Voltage : Approx. 2.5V
Maximum Short Test Current : Approx. 0.1mA
Continuity Threshold : Adjustable 10 to 50 Ω, default
30Ω.
Continuity Indicator : 2kHz Tone Buzzer
Range Resolution Accuracy
400.0Ω 0.1Ω 0.2%+2d
