Testing Diodes
Maximum Open Circuit Voltage : Approx. ±2.5V
Maximum Short Test Current : Approx. ±1mA
Range Resolution Accuracy
2.000V 1mV 1.5%+2d
Capacitance
Range Resolution Accuracy
40.00nF
400.0nF
4.000uF
40.00uF
10pF
100pF
1nF
10nF
400.0uF
4.000mF
40.00mF
100nF
1uF
10uF
0.9%+20d
0.9%+10d
0.9%+2d
0.9%+10d
0.9%+20d
Measuring Time
1 sec
1 sec
1 sec
1 sec
1 sec
4 sec
8 sec
Temperature (only 502)
Range Resolution Accuracy
-200°C to+1200°C 1mV 1.5%+2d
-328°F to +2192°F 0.1°F 1.0%+4°F
[1] Does not include error of the thermocouple probe.
[2] Accuracy specification assumes ambient temperature
stable to ± 1°C. For ambient temperature changes of
± 2°C, rated accuracy applies after 1 hour.
501 / 502
