Power On Options
ENTER
A HOLD
Display the firmware version.
Display all LCD segments.
Select measurement function.
Select measurement range.
Press > 1 sec to enter auto range mode.
Enable/Disable the High Frequency Reject mode in the
AC measurements.
Enter menu function in pointer positon.
Enable the Peak-Hold mode in the AC or DC
measurements.
In this mode, press button to select Peak-Hold MAX
or MIN. Press > 1 sec to disable the Peak-Hold mode.
Select degrees Celsius or degrees Fahrenheit.
Enable/Disable the Auto-Hold mode.
Push Buttons
Cancel current menu function.
°C / °F
Enable/Disable the Hz mode in the AC measure-ments.
Function
(Yellow)
RANGE
HFR
A-HOLD
P-HOLD
ENTER
CANCEL
Hz
When turn the power on, press the function button to
execute the below options.
Power On Options
Making Basic Measurements
Warning
!
• When connecting the test leads to the DUT (Device
Under Test), connect the common test lead before
connecting the live lead. When removing the test leads,
remove the test live lead before removing the common
test lead.
The following sections describe how to take measure-
ments with the meter.
501 / 502
EN
