70 Chapter 5
5 Locate the long PCI slots at the back left side of the server.
You can install a card in one or both slots. Cards are oriented horizontally in the server. The
long PCI cards fit into an assembly unit that contains the sockets for both cards.
Depending on which slot has a card in it and how many cards you want to install, you may
need to remove a card to install an another PCI card in the other slot.
PCI card slots (2)
