34 Chapter 3
Place the Server in the Rack
Once you’ve attached the cover, you can put the server into the rack.
1 At the front of the rack, lift the server to the level where the enclosure’s cover is installed and
slide the server into the cover.
2 Secure the server in the rack by tightening the thumbscrews on the front.
3 To further secure the server and prevent removal of the drive modules, use the enclosure key
(supplied with the server) to fasten the security lock on the front panel. (See the illustration
above.)
Insert the server into the cover
and slide it all the way back.
To secure the drive modules in the
server, use the enclosure key to lock
them in place.
Tighten the two thumbscrews
to secure the server in the rack.
