Appro LC-7516 - Specifications

88
7. SPECIFICATIONS
Image sensor 1/2.8” 3M Sony IMX036 CMOS sensor.
The LC-7516 IP box camera:
3.1~8mm CS mount Vari-Focal Megapixel Lens
Lens
The IP mini-dome LC-7526/ LC-7536 & the IP bullet camera
LC-7556:
3~9mm Vari-Focal board type Megapixel Lens
Minimum illumination Color: 0.2 Lux @ F1.2; B/W: 0.01 Lux @ F1.2
IR cut filer Yes
Camera
Day & Night Auto / Day / Night / Schedule.
Video Compression H.264 / MPEG4 / MJPEG.
Resolution
 4:3 - “2048x1536”
(H.264 & MJPEG only), “1600x1200”,
“1024x768“, “800x600”, “640x480”, “480x360”, “320x240”
and “176x144”.
 16:9 - “1920x1080”, “1280x720”, “800x450”, “640x360”,
“480x270”, “320x176” and “176x144”.
Frame Rate
15 fps at 2048x1536; 25 fps at 1920x1080
Support WDR @ 1080p @ 25 fps
Video streaming
- Simultaneous H.264, MPEG4 and MJPEG.
- Multi-profile: resolution / compression / frame rate / video
quality.
Profiles 3 (selectable)
Image settings
- Adjustable image size, quality, and bit rate.
- Day / Night mode.
- Flip & Mirror.
- AGC, AWB, AES.
- Time stamp and text caption overlay.
- Privacy masks.
- Exposure Mode
Video management
software
SDK, including HTTP-API / ActiveX / ONVIF.
Audio streaming Two-way.
Compression G.711u / G.726.
Audio bit rate G.711u 64kbps / G.726 32kbps.
Audio
Inputs / outputs: 1 x input / 1 x output (3.5mm earphone jack).
Security
Multi-level password protections, IP address filtering, HTTPS
encryption, User access log.
Protocols
IPv4, HTTPS, HTTP, TCP, UDP, RTP/RTCP/RTSP, DHCP, NTP,
FTP, SMTP, UPnP, ICMP, ARP, DDNS, PPPoE, SAMBA
Users Access by 10 simultaneous users.
Network
Firmware update SD card / HTTP.
Recording SD card, SAMBA, FTP
Pre-alarm recording Yes.
Advanced motion 512 zones. Sensitivity: 0 - 100 %.
Trigger
Motion Detection
Schedule
Alarm input
Ethernet loss
Network/Remote digital alarm input
Alarm
Notification SD card recording, SMTP, FTP, HTTP, alarm output.
