2.3 The LC-7556 Bullet IP Camera Indoor/ Outdoor (PoE)
The component parts ( the internal view ).
Dismantle the bullet IP camera to see its different parts. The picture here shows you the internal
component items making up the product.
SCREWS
SUN SHIELD
SD PCB
LENS
FAN
FRONT CASE
IR PCB
SENSOR PCB
PCB PLATE
POWER PCB
MIDDLE CASE
WATERPROOF RUBBER
REAR CASE
Camera with bracket ( the external view ).
The picture here shows the camera's exterior, with the bracket screwed in and fixed to it. The
bracket enables you to easily mount the camera on a wall, turned at the angle you want.
NOTE: Use the 2 screws to screw the sun shield (above) into the 2 extreme holes indicated
in the bullet camera (below) to get an unobstructed viewing angle.
Please don’t use the middle hole in the camera, as that will block the view.
