QUICK REFERENCE TO CONTROLS & DISPLAY
NON-PROGRAMMABLE MODELS (8444, 8446, 8448)
PROGRAMMABLE MODELS (8463, 8465, 8466)
NOTE: BACKLIGHT IS ACTIVATED WITH FIRST BUTTON PRESS AND AUTOMATICALLY TURNS OFF.
NOTE: BACKLIGHT IS ACTIVATED WITH FIRST BUTTON PRESS AND AUTOMATICALLY TURNS OFF.
CURRENT INDOOR TEMPERATURE
SYSTEM MODE
SETTING
FAN SETTING
SYSTEM MODE
FAN
BATTERY DOOR
MESSAGE CENTER LOW BATTERY WARNING
QUICK REFERENCE CARD
OUTDOOR TEMPERATURE (OPTIONAL)
TEMPERATURE SETTING
EQUIPMENT STATUS
EMERGENCY HEAT (RED)
SYSTEM FAULT (YELLOW)
INDICATOR SHOWS THROUGH HOUSING
HEAT PUMP MODELS ONLY
UP
DOWN
CURRENT INDOOR TEMPERATURE
SYSTEM MODE
SETTING
FAN SETTING
SYSTEM MODE
FAN
BATTERY DOOR
MESSAGE CENTER LOW BATTERY WARNING
QUICK REFERENCE CARD
OUTDOOR TEMPERATURE (OPTIONAL)
TEMPERATURE SETTING
EQUIPMENT STATUS
UP
DOWN
PROGRAM
CURRENT
SCHEDULE
PERIOD
HOLD
CURRENT TIME
EMERGENCY HEAT (RED)
SYSTEM FAULT (YELLOW)
INDICATOR SHOWS THROUGH HOUSING
HEAT PUMP MODELS ONLY
