44. Engine oil plug
45. Right hand fairing lug
46. Engine oil level
47. Gear lever
48. Right hand rider footrest
49. Rear tone wheel
50. Rear brake pump and fluid res-
ervoir
51. Rear right turn indicator
44. Dop van de motorolie
45. Beslag rechterzijbekleding
46. Peil van de motorolie
47. Versnellingshendel
48. Rechter voetsteun bestuurder
49. Achterste geluidswiel
50. Pomp en remvloeistof tank ach-
teraan
51. Rechter richtingaanwijzer ach-
teraan
02_03
23
2 Vehicle / 2 Voertuing
