Compression adjustment, knob (2) open (**) 1.5 click from fully closed
(*)
Regeling in compressie, bout (2) vanuit de stand gesloten (*),
openen (**) 1,5 slag
REAR SHOCK ABSORBER - RSV4 R - RACING
ADJUSTMENT RANGE (TRACK USE ONLY)
Shock absorber centre-to-centre
distance (A)
311.5 +/- 1.5 mm (12.26 +/- 0.059
in)
(preloaded) Spring (B) length 144 mm + 3 turns (5.67 in)
Rebound adjustment, ring nut (1) open (**) 8 +/- 1 clicks from fully
closed (*)
Compression adjustment, knob (2) open (**) 0.5 click from fully closed
(*)
ACHTERSTE SCHOKDEMPER - RSV4 R - RANGE
REGELING RACING (ENKEL GEBRUIK OP CIRCUIT)
Hartafstand van de schokdemper
(A)
311.5 +/- 1,5 mm (12.26 +/- 0.059
in)
Lengte van de veer (voorbelast)
(B)
144 mm + 3 slagen (5.67 in)
Regeling in extensie, moer (1) vanuit de stand helemaal gesloten
(*), openen (**) 8 +/- 1 klikken
Regeling in compressie, bout (2) vanaf alles gesloten (*), openen
(**) voor 0,5 draai
(*) = clockwise
(**) = anticlockwise
(*) = rechtsom
(**) = linksom
93
