CHASSIS NUMBER
The chassis number is stamped on the front frame;
to read it, open the glove-box and remove the pro-
tection cover.
Engine number
The engine number is stamped on the rear side,
next to the left shock absorber.
Dimensions and mass
WEIGHT AND DIMENSIONS
Specification
Desc./Quantity
Max. length 2040 mm
Max. width 720 mm
Max. height (to windshield) 1372 mm
Saddle height 810 mm
Wheelbase 1391 mm
Minimum ground clearance 145 mm
Weight in running order (kerb weight) 154 kg
Engine
ENGINE TECHNICAL DATA
Specification
Desc./Quantity
Engine model BB01 (125)
CB01 (200)
Engine type Single-cylinder, 4-stroke, 4 valves, wet sump forced lubrication
system, double overhead camshaft.
Overall engine capacity 124.2 cm³ (125)
180.8 cm³ (200)
Bore/stroke 58 mm x 47 mm (125)
63 mm x 58 mm (200)
Compression ratio 12.0 ± 0.5 : 1 (125)
11.6 ± 0.5 : 1 (200)
Valve clearance Intake: 0.10 to 0.15
Exhaust: 0.20 - 0.25
Ignition starter
Idle speed 1900 ± 100 rpm (125)
1800 ± 100 rpm (200)
Clutch Automatic centrifugal dry clutch
SCARABEO 125 i.e. - 200 i.e. Characteristics
CHAR - 13
