FORK REMOVAL
•
Drain off the oil.
•
Place the stem in a vice fitted with pro-
tection shoes (aluminium).
•
Unscrew and remove the lower screw
«1» and collect the washer.
•
Slide off the stem from the sleeve and
collect the bushing.
•
Slide off the pumping member pin «2»
from the stem and collect the spring
«3».
•
Slide off the dust guard «4» from the
sleeve.
SCARABEO 125 i.e. - 200 i.e. Suspensions
SUSP - 159
