APRILIA scarabeo 125 i.e. User Manual

This section describes the operations to be carried out on the engine and the tools required.
Automatic transmission
Transmission cover
•
Remove the air duct.
•
Undo and remove the twelve external
screws of the cover.
•
Remove the transmission cover.
•
Remove the bushing from the support-
ing bearing of the driven pulley shaft on
the transmission cover by placing a
screwdriver in the slot on the transmis-
sion cover.
Air duct
•
Unscrew and remove the two screws
(1).
•
Undo and remove the three screws (2).
•
Remove the air duct.
Engine SCARABEO 125 i.e. - 200 i.e.
ENG - 74
