DEVICE STATUS
Specification Desc./Quantity
Engine status (Off/running) Engine off or running
Rpm sensor (Synchronised/Not synchron.) Synchronised if the control unit detects a correct synchronisa-
tion (by means of the crankshaft rpm detection sensor
Idle/full load (on/off) ON if idle functioning
Active lambda probe (on/off) ON if the control unit is using the lambda probe signal to keep
the stoichiometric combustion
ADJUSTABLE PARAMETERS
Specification Desc./Quantity
Throttle position self-acquisition Just press the ENTER button to save the throttle closed posi-
tion
Self-adjustable parameters reset Lambda probe self-adaptability parameters reset (if a new en-
gine, a new lambda probe or a new injector is installed)
DEVICES ACTIVATION
Specification Desc./Quantity
Error clearing Press "enter" to transfer errors from the memory (MEM) to the
historical record (STO). The next time Axone is connected to
the ECU, the errors in the historical record (STO) will no longer
be displayed
Fuel pump The device is activated: if it is not correctly activated, this will
be immediately shown in the Axone screen page
Coil The device is activated: if it is not correctly activated, this will
be immediately shown in the Axone screen page
Injectors The device is activated: if it is not correctly activated, this will
be immediately shown in the Axone screen page
Electric fan The device is activated: if it is not correctly activated, this will
be immediately shown in the Axone screen page
Idle motor The device is activated: if it is not correctly activated, this will
be immediately shown in the Axone screen page
ERRORS DISPLAY
Specification
Desc./Quantity
Throttle If the throttle position sensor signal is interrupted
Pressure If the atmospheric pressure sensor signal is interrupted
Lambda probe Displayed if the probe signal circuit is interrupted
Water temperature Sensor, circuit or relevant connectors interrupted
Air temperature (°C) Sensor, circuit or relevant connectors interrupted
Battery voltage
Injector Sensor, circuit or relevant connectors interrupted
Coil Sensor, circuit or relevant connectors interrupted
Idle motor Sensor, circuit or relevant connectors interrupted
Fuel pump relay
Electric fan Sensor, circuit or relevant connectors interrupted
Self-adjustable parameters
RAM memory Control unit internal error
ROM memory Control unit internal error
EEPROM Control unit internal error
Microprocessor Control unit internal error
Rpm sensor If the crankshaft rpm detection sensor is disconnected, this er-
ror is not shown
SCARABEO 125 i.e. - 200 i.e. Injection
INJEC - 139
