CHAPTER 2
TECHNICAL SPECIFICATIONS
Entire Contents Copyright  2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000 Series 2 - 3 OM-001-01000-000-04.0
Input Electrical Specifications
Model
1003
1005
1010
1020
1030
1040
1060
Input Phase
1-phase / 2-wire + Ground
3-phase
Input Voltage(VAC L/L)
230 V ± 15%
208,220,240(3W+G)380,415,480(4W+G)±10%
Input Frequency
47 – 63 Hz
Output Electrical Specifications
Total Power
3 KVA
5 KVA
10 KVA
20 KVA
30 KVA
40 KVA
60KVA
Maximum
Amps
0 – 150 V 25.2 A 42.0 A 84.0 A 168.0 A 252.0 A 336.0 A 504.0 A
0 – 300 V
12.6 A
21.0 A
42.0 A
84.0 A
126.0 A
168.0 A
252.0 A
Phase
1-phase / 2-wire + Ground
Voltage
Low Range
0 – 150 V
High Range
0 – 300 V
Resolution
0.1 V
Accuracy
± (1% + 0.2 V)
Frequency
Range
45 – 500 Hz
Resolution
0.1 Hz at 45 – 99.9 Hz, 1 Hz at 100 – 500 Hz
Accuracy
±
0.2%
Parameters
1003P
1005P
1010P
1020P
1030P
1040P
1060P
Current
Range
L
0.000 – 3.5 A 0.00 – 35.00 A 0.0-350A
H
3.00 – 35.00 A
30.00 – 350.0 A
300-3500A
Resolution
L
0.001 A
0.01 A
0.1A
H
0.01 A
0.1 A
1A
Accuracy
L
± (1% of reading + 0.005
± (1% of reading + 2 counts)
H
± (1% of reading + 0.01 A)
± (1% of reading + 1 count)
Power
Range
L
0.0 – 350.0 W
0.000 – 3.500 kW
0.0-35.0kW
H
300 – 5000 W
3.00 – 60.00 kW
30.0-
Resolution
L
0.1 W
0.001 kW
0.01kW
H
1 W
0.01 kW
0.1kW
Accuracy
L
±
(1.5% of reading + 0.5
±
(1.5% of reading + 5 counts)
H
± (1.5% of reading + 1.0
± (1.5% of reading + 1 count)
Power
Factor
Range
0.001 – 1.000
Resolution
0.001
Accuracy
Depends on the accuracy of V, A, W
Harmonic Distortion
≤
1% (Resistive Load)
Crest Factor
≥ 3 to 1
Load Regulation
±
0.5%
Protection
Over-Current, Short-Circuit, Over-Temperature
Efficiency
≥
85% (at full load)
