CHAPTER 2
TECHNICAL SPECIFICATIONS
Entire Contents Copyright  2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000 Series 2 - 5 OM-001-01000-000-04.0
Mechanical Specifications
Model 1003 1005 1010 1020 1030 1040 1060
Power Rating
3 KVA
5 KVA
10 KVA
20 KVA
30 KVA
40 KVA
60KVA
Dimensions (In.) H
12
12
28
33
43
43 66
D 26 26 29 29 39
39 39
W
17
17
17
17
24
24 32
Weight Kg 95 125 228 350 592
663 885
lbs
210
275
503
772
1305
1462 1951
Displays and Controls
Model 1003 1005 1010 1020 1030 1040 1060
4 Digital LED
meters
Frequency, Voltage, Current, Power or Power Factor (simultaneously)
PLC Remote Output ON/OFF
Selection of programmable memories: P1, P2, P3
Memory 8 Memories, 5 Programmable Steps per Memory for:
Voltage, Frequency, Test Time, Delay Time, Current, Power, and
Power Factor Hi/Lo Limit Setting
Note: Programmable memories can be manually programmed and used independently of the
External RS-232 or GPIB Interface. They can also be independently programmed through
these external interfaces.
Calibration Front Panel Calibration
PLC
(external)
Interface
PLC interface controls execution of programmed steps in Memories 1, 2, or 3.
The PLC interface is a standard feature of all APS Power Converters.
Auto-Voltage
Adjust
Provides improved voltage regulation
Environmental Specifications
Operating Temperature 32 ºF – 104 ºF (0 ºC – 40 ºC)
Relative Humidity < 80 % (Non-condensing)
Altitude ≤ 6,500 feet
