Aputure Light Storm LS 600d - Connecting to DMX; DMX Controller Connection; Channel Selection

1
2
3
4
5
1
2
3
4
5
1
2
3
4
5
-17-
2) Channel Selection
* The default DMX channel is "001".
** The range of DMX channels is 1 to 512.
In DMX mode, match the channel of your DMX controller with the light, and then adjust
accordingly.
* The DMX interface schematic is shown in the pictures below:
4. Connecting to DMX
1) Connect a standard DMX controller
Connecting DMX to only one 600d
Daisy chaining multiple lights using DMX
Signal Common
Data 2+ (Optional Secondary
Data Link)
Data 2- (Optional Secondary
Data Link)
Signal Common
Data 2+ (Optional Secondary
Data Link)
Data 2- (Optional Secondary
Data Link)
DMX512
DMX512
OUTPUT
DMX512
DMX512
OUTPUT
1
1
2
3
4
5
2
3
4
5
Data 1+ (Primary Data Link)
Data 1- (Primary Data Link)
1
2
3
4
5
Data 1+ (Primary Data Link)
Data 1- (Primary Data Link)
