ilux Digital Bath with diverter installation instructions Page 8
Choose the position for the Digital processor as close to the Digital diverter as
possible, within range of the 2m connecting data cable provided. The Digital
processor and diverter assembly must be sited as close to the bath controller as
possible, within range of the 10m data cable provided for connecting the processor to
the controller. The processor and diverter may be sited in the roof space above the
proposed bath site, in the airing cupboard or behind a screwed bath panel if more
convenient. If siting in the roof space, ensure that freezing cannot occur and that no in-
sulation material is placed under or over the processor and diverter.
Please refer to the system layout diagrams overleaf.
3
!
THE PROCESSOR AND DIVERTER MUST BE SITED IN A POSITION THAT IS SAFELY AC-
CESSIBLE FOR SERVICING AND COMMISSIONING PURPOSES. WHEN FITTED IN THE
LOFT SPACE, THE ROUTE TO AND THE AREA AROUND THE PROCESSOR MUST BE
BOARDED TO ENSURE A SAFE WORKING ENVIRONMENT.
The optimum position for the Digital processor and diverter is in the roof space above
the bath site to take full advantage of the ease and speed of installation - please refer
to the note above.
The distance between the Digital processor and bath control must be within range of the
10m data cable supplied.
The Digital diverter valve inlet has been designed to enable connection directly inline
with the HP/Combi Digital processor outlet isolation valve connection or off the Gravity
Pumped Digital processor outlet using the cranked elbow connection fitting.
The distance between the Digital diverter valve and processor must be within the
2m range of the patch lead data cable connection provided.
