ARB 3412620 - Page 4

Last Rev Date: 13/12/2022
Page 4 of 20
Fitting instructions# 37801222
Copyright © 2022 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
REFITMENT OF TOW
HOOK
4581011
4
WASHER FLAT M12X27X4
WINCH AND CONTROL
BOX FITMENT
(REQUIRES KIT 3512140)
180302
3755049L&R
3756499
4581040
4584327
4584329
4584393
5848302
6151074
6151223
6151443
6151459
6151547
6151561
6151684
EG50
4
1L1R
1
4
4
8
4
2
2
2
2
8
2
8
2
2
CABLE TIE 4.8 X 180 MM
NUMBER PLATE MOUNT BRKT LHS/RHS
BRACKET CONTROL BOX MNT MULTI FIT
WASHER FLAT M10 x 25 x 3 | TZP480
WASHER FLAT M6X16X1.2 | BTZP480
WASHER FLAT M6X12.2X1.2 | BTZP480
WASHER FLAT M8x19x2 | HV300 BTZP480
PACKER RB NYLON
BOLT HXHD 3/8 UNCx1 3/4
NUT HEX NYLOC M6X1.0 | ZNB480
SCREW BHD M6x20 | BLK
SCREW BHD M6x16 | BTZP480
NUT HEX NYLOC 8x1.25 | PC8.8 BTZP480
NUT FLANGE M6X1.0 | BTZP480 SERRATED
SCREW HXHD M8x1.25x30 | PC8.8 BTZP480
RUBBER GROMMET
3412650 / 3412660 / 3412670
DUAL CAB PARTS LISTING
APPLICATION.
PART NO.
QTY
DESCRIPTION
BULL BAR TO CHASSIS
5848414
5848357
5848419
6151686
4584366
6151249
4584377
6151528
4
4
2
8
8
2
4
2
PACKER SIDE LC70 SERIES
PACKER 78 SERIES BAR
PACKER TOP/BOTTOM 4mm LC70
BOLT HXHD M10x1.25x30 | FT PC10.9 TZP480
WASHER FLAT M10X30X4 | HV300 TZP480
BOLT HXHD FL M12x1.25x170 | PC11.9 ZAB1000
WASHER FLAT M12X30X5
NUT HEX NYLOC M12X1.75 | PC10.9 ZP
INDICATORS TO BULL
BAR
6821287
6821116
1
4
LAMP KIT LED | INDICATOR CLEARANCE
GROMMET NYLON SQUARE | SNAP IN TYPE
FOG LAMP HOUSINGS
TO BULL BAR
(NOT INCLUDED IN
3412670)
3163082
1
KIT SURROUND ARB FOGLIGHT
