ARB 3412620 - Page 5

Last Rev Date: 13/12/2022
Page 5 of 20
Fitting instructions# 37801222
Copyright © 2022 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
RADAR CONTROL
MODULE FITMENT
3163339
3755071
3755047
6151223
4584327
6151561
6151443
6151459
6151525
6821189
6151384
5848302
6821456
1
1
1
6
14
2
2
4
2
4
4
2
1
RADAR COVER | SUITS LC76 - 79 MY 22 ON
LC70 TSS RADAR BRKT
LC70 TSS RADAR MOUNT BRKT
NUT HEX NYLOC M6X1.0 | ZNB480
WASHER FLAT M6X16X1.2 | BTZP480
NUT FLANGE M6X1.0 | BTZP480
SCREW BHD M6x20 | BLK
SCREW BHD M6x16 | BTZP480
SCREW BHD M6x1.0x25 | BZP
GROMMET RND FL 1500 080 090
SCREW ST PHD 5.2x16 | PH PC8.8 BTZP480
PACKER RBAR NYLON
RADAR HARNESS EXTENSION
NUMBER PLATE FITMENT
3755048
6151975
4581304
6151128
6151459
4584329
6151561
1
4
4
4
2
2
2
NUMBER PLATE BRKT | WINCH FIT KIT 70 SERIES
SCREW BTN HD M6 X 12 SS
WASHER FLAT M6 | SS
NUT FLANGE M6X1.0 | ZP
SCREW BHD M6x16 | BTZP480
WASHER FLAT M6X12.2X1.2 | BTZP480
NUT FLANGE M6X1.0 | BTZP480
REFITMENT OF TOW
HOOK
4581011
4
WASHER FLAT M12X27X4
WINCH AND CONTROL
BOX FITMENT
(REQUIRES KIT 3512140)
180302
3755049L&R
3756499
4581040
4584327
4584329
4584393
5848302
6151074
6151223
6151443
6151459
6151547
6151561
6151684
EG50
4
1L1R
1
4
4
8
4
2
2
2
2
8
2
8
2
2
CABLE TIE 4.8 X 180 MM
NUMBER PLATE MOUNT BRKT LHS/RHS
BRACKET CONTROL BOX MNT MULTI FIT
WASHER FLAT M10 x 25 x 3 | TZP480
WASHER FLAT M6X16X1.2 | BTZP480
WASHER FLAT M6X12.2X1.2 | BTZP480
WASHER FLAT M8x19x2 | HV300 BTZP480
PACKER RB NYLON
BOLT HXHD 3/8 UNCx1 3/4
NUT HEX NYLOC M6X1.0 | ZNB480
SCREW BHD M6x20 | BLK
SCREW BHD M6x16 | BTZP480
NUT HEX NYLOC 8x1.25 | PC8.8 BTZP480
NUT FLANGE M6X1.0 | BTZP480 SERRATED
SCREW HXHD M8x1.25x30 | PC8.8 BTZP480
RUBBER GROMMET
