14. Pull the grille forward and unplug the
radar module located behind the
Toyota badge.
15. Place the grille face down on a soft
surface, remove radar using a Phillips
head screwdriver and place in a safe
spot
Warning: Care must be taken not to
damage radar module.
16. Fit grille back onto vehicle. Make sure
to clip in the retaining mechanism
first.
17. Plug the provided radar extension
loom into the vehicle radar loom and
feed underneath grille.
