11. When complete, the vehicle should be
presented as shown.
IF VEHICLE IS NOT FITTED WITH
FORWARD FACING RADAR,
PROCEED TO STEP 18.
12. Remove four screws located on the
top of the front grille.
13. Remove the grille by unclipping
retaining mechanism located at the
inside bottom corner of the grille.
