ARB 3432050 - Page 2

25-9-98 Page 2 of 6 3782513
FITTING KIT (TO SUIT BOTH BULL BARS) No. 6171239
PART No
QTY
DESCRIPTION
USE
3500080
1
INDICATOR KIT (contains L and R)
TURN SIGNAL INDICATORS
6151017
2
M6 X 16mm BOLT
NUMBER PLATE TO BULL BAR
6151046
2
M6 FLAT WASHER
6151128
2
M6 FLANGE NUT
3500200
1
BUFFER KIT
RUBBER BUFFER TO BULL BAR
3751627L
1
IMPACT ABSORBER (LHS)
IMPACT ABSORBERS AND
3751627R
1
IMPACT ABSORBER (RHS)
MOUNT ASSEMBLY TO CHASSIS
5846273
2
CHASSIS PACKER INSIDE
5846274
2
CHASSIS PACKER OUTSIDE
6151105
4
1/2" X 4 1/2" BOLT
6151106
2
1/2" X 5" BOLT
4581007
2
40mm HEAVY DUTY WASHER
4581050
6
1/2" SPRING WASHER
4581049
10
1/2" FLAT WASHER
6151138
6
1/2" NUT
180302
1
CABLE TIE
6151087
8
M10 X 25mm BOLT
BULL BAR TO IMPACT ABSORBER
4581048
8
M10 SPRING WASHER
4581039
16
M10 FLAT WASHER
6151033
8
M10 X 1.25 NUT
ADDITIONAL FITTING KIT FOR THE WINCH BULL BAR No. 6171223
PART No
QTY
DESCRIPTION
USE
6151118
2
1/4" NUT
CONTROL BOX TO CONTROL BOX
4581035
2
M6 FLAT WASHER
BRACKET:
4581036
2
M6 SPRING WASHER
(A) For 8 or 9,000lb winch
6151118
4
1/4" NUT
CONTROL BOX TO CONTROL BOX
6151068
2
1/4" X 1" BOLT
BRACKET:
4581036
4
M6 SPRING WASHER
(B) For 10,000lb winch
3751619
1
CONTROL BOX BRACKET
CONTROL BOX BRACKET
6151021
2
M8 X 20mm BOLT
TO BULL BAR
4581044
2
M8 FLAT WASHER
6151132
2
M8 FLANGE NUT
BLR850
1
WIRING LOOM RED
CABLES 10,000lb WINCH ONLY
BLB850
2
WIRING LOOM BLACK
(supplied with winch guard)
6151094
2
M12 X 30 mm BOLT
ROLLER FAIRLEAD TO BULL BAR
4581050
2
1/2" WASHER SPRING
4581049
4
1/2" WASHER FLAT
6151135
2
M12 X 1.25 NUT
4601021
1
WINCH MOUNT CRADLE
WINCH MOUNT CRADLE TO CHASSIS
4581040
4
3/8” FLAT WASHER
WINCH 8 OR 9,0000lb ONLY
4581042
4
7/16” WASHER FLAT
WINCH 10,0000lb ONLY
