Revision Date – 22/12/2014 page 65
9.19 Lid seal – Remove and Refit
Locate and mark the join in the lid seal as shown.
Using a pair of long nosed pliers, grip the seal
and pull it away from the lid.
Starting at the marked point, press the seal into
the grove.
NOTE: The seal should be orientated with the
groove on the side as shown.
The lid seal is cut to the correct length and should
fit exactly into the grove.
If the seal is too long, it may have been over-
stretched. Remove the seal and refit it without
stretching.
If the seal is too short, remove the seal and
reinsert it while stretching it slightly.
