ARB AIRLOCKER RD208 - Removing the Differential Carrier

2 Removing the Existing Differential
8
2.6 Removing the Differential Carrier
 Remove the adjuster nut locking tabs.
 Remove the bearing caps from the third member.
 Remove the adjuster nuts.
 Carefully remove the differential carrier from the third member.
 Remove the tapered roller bearings from the differential carrier with
a bearing puller. (Fig.3.)
HINT : Check the condition of the bearings for wear and
replace if necessary.
Figure
3.
