3.9 Profiling the Seal Housing Tube
 With the seal housing tube now firmly secured into the bulkhead
fitting, bend the tube so that it closely follows the profile of the
differential. (Figs.14., 15. & 16.)
 Check that the contour of the tube will not interfere with the bearing
caps, the Air Locker or the ring gear.
Figure
14.
Figure
15.
