ARB AIRLOCKER RD208 - Page 20

3 Installing the Air Locker
18
Figure
13.
NOTE : Make sure the seal housing tube is all of the way into
the center compression nut while you are tightening
it.
NOTE : Firmly tighten the center compression nut so that a
good seal is formed around the tube.
