ARB AIRLOCKER RD208 - Itemized Parts List

7 Parts List
36
7.3 Itemized Parts List
(See exploded diagram figure 25.)
ITEM #
QTY
DESCRIPTION
PART #
NOTES
01
1
FLANGE CAP KIT
028513SP
02
1
BONDED SEAL
160701SP
03
1
CLUTCH GEAR & WAVESPRING KIT
050908SP
04
2
SHORT CROSS SHAFT
060309SP
05
1
LONG CROSS SHAFT
060108SP
06
1
SIDE GEAR
SEE NOTE
2
07
2
SIDE GEAR THRUST WASHER
SEE NOTE
08
1
COUNTERSUNK SCREW (PK OF 2)
200213SP
09
1
RETAINING PIN SET (PK OF 4)
120601SP
10
-
TAPERED ROLLER BEARING
NOT SUPPLIED
11
1
SEAL HOUSING RETAINING CLIP
150601SP
12
1
SEAL HOUSING KIT
081902SP
13
1
SEAL HOUSING O-RINGS (PK OF 2)
160235-2
1
14
1
ADJUSTER NUT
100101SP
15
1
WAVESPRING
150702SP
16
1
SPLINED SIDE GEAR
SEE NOTE
2
17
4
PINION GEAR
SEE NOTE
2
18
4
PINION THRUST WASHER
SEE NOTE
19
1
SPIDER BLOCK
070702SP
20
1
DIFFERENTIAL CASE
013113SP
*
1
BULKHEAD FITTING KIT (BANJO TYPE)
170114
4
*
1
AIR LINE (6mm DIA X 6m LONG)
170314SP
4
*
1
SOLENOID VALVE (12V)
180103
*
1
SWITCH|FR OR RR LOCKER
180225
*
1
CABLE TIE (PK OF 25)
180305
*
1
OPERATING & SERVICE MANUAL
210200
*
1
INSTALLATION GUIDE
2102208
*
Not illustrated in exploded view
NOTES
1
For replacement O-rings use only BS133 Viton 75.
2
Available only as complete 6 gear set # 728JA12
3
Available only as complete thrust washer kit #730JA01
4
All diffs produced before serial #17070001 came with 5mm air connection system.
For information contact ARB.
-
For seal housing set-up refer to tech note (Section 5.2).
-
For 22 spline model refer to RD205 (Section 2.205)
Part No. 2102208
Revision 27/10/2020
