10
3.2 Strap Installation
Step 1: Separate the velcro.(See Pic 9)
Pic 9
Step 2: Pull out one side through the
strap hole on the front panel with hook
side of the velcro up.(See Pic 10)
Pic 10
Step 3: Pull out it to well stick hook side
of the velcro to loop side and across
the nylon buckle.
Repeat it on the other side.(See Pic 11)
Pic 11
Step 4: Adjust the length by pulling the
nylon buckle (as shown in the
picture).(See Pic 12)
Pic 12
Step 5: Proper state after installation:
1. Strap does not twist;
2. Buckle side of shoulder pad is up,
while its flat side faces the machine (as
shown in the picture);
3. Straps are well locked.(See Pic 13)
Pic 13
