4
2. PRODUCT DESCRIPTION
2.1 Technical parameters
2.2 Size and weight
Model CUT50
Overall size (L*W*H)
474*150*244mm/18.7*5.9*9.6in
Weight (kg) 6kg/13lb
Items
Models
CUT50
Rated input power supply Single-phase AC110V 50Hz Single-phase AC220V 50Hz
Rated input capacity (kVA) 5.0 7.9
Power factor 0.63
Rated output (A/V) 35/94 50/100
Rated duty cycle (%) 60
No-load voltage (V) 280
Output current range (A) 20~35 20~50
Arc ignition mode HF contact
Post-flow time (s) 5~15
Gas pressure range (Mpa) 0.3~0.5
Insulation grade H
Cooling mode Air cooling
Enclosure ingress protection IP21S
Efficiency (%) 84
