7
2) Ordering and Packing List
Name Specification Quantity (pcs)
TIG welder TIG200 1
TIG torch & accessories WP-17 (13ft/4m) 1
Electrode Holder
200A-16mm
2
（
9ft/ 3m
）
DKJ 35-50
1
Earth clamp
300A-16mm
2
（
9ft/ 3m
）
DKJ 35-50
1
Operator’s manual Operator’s manual of TIG200 1
Gas hose Gas hose with gas connector 1
Conversion adapter American adapter plug 1
Strap 0.1*4.3ft (30mm*1500mm), Black 1
Tungsten electrode
φ
1/16”, 6”
（
1.6mm, 150mm)
1
2.5 System characteristics
Duty Circle
Rated duty circle means: Taking 10 min as a time cycle, the ratio of rated output time is taking in that
time cycle, as shown in Pic 3.
Static External Characteristics
TIG series welders’ power output is of dropping characteristics (constant current characteristics), as
shown in Pic 4. Picture is only for reference.
Pic 3 Duty Circle Sketch Map Pic 4 Output characteristic curves
