4.4 Strap Installation
Step 1: Separate the velcro.(See Pic 13)
Pic 13
Step 2: Pull out one side through the strap hole
on the front panel with hook side of the velcro
up.(See Pic 14)
Pic 14
Step 3: Pull out it to well stick hook side of the
velcro to loop side and across the nylon buckle.
Repeat it on the other side.(See Pic 15)
Pic 15
Step 4: Adjust the length by pulling the nylon
buckle (as shown in the picture).(See Pic 16)
Pic 16
Step 5: Proper state after installation:
1. Strap does not twist;
2. Buckle side of shoulder pad is up, while its
flat side faces the machine (as shown in the
picture);
3. Straps are well locked.(See Pic 17)
Pic 17
