72-DVTE30-2
3
INTRODUCTION
Congratulations on choosing an Archgard fireplace!
The Optima 72-DVTE30-2 is one of the most advanced direct vent fireplace heaters available. It is solidly designed using
the latest technology and manufactured to the highest quality. It is our aim to provide you with an appliance for many
trouble-free years of reliable service.
The following are just some of the many features of your new gas fireplace:
Please read the manual carefully prior to installation and operation of the appliance. Proper installation,
operation and maintenance of the appliance will provide you with many years of enjoyment.
Please complete and submit the warranty registration card included in the back of this manual
or by visiting us at:
www.archgard.com/warranty-registration
• Heater Classification
The 72-DVTE30-2 is classified as a heating appliance. In conjunction with an op-
tional thermostat, the Optima 72 can be operated continuously for zone heating.
• High Efficiency
The 72-DVTE30-2 has one of the highest efficiencies of any fireplace, which
means that it is less expensive to operate.
• Adjustable Fan Speed
Heat circulation fan is fully adjustable. The fan can be adjusted through 6 speeds
to suit your comfort level.
• Adjustable Flame
The flame aesthetics and heat output can be adjusted to suit your heating needs.
• Solid Construction
The 72-DVTE30-2 is constructed mainly of 14 and 18 gauge galvanized and alu-
minized steel for long life and durability.
• Electronic Control System
This fireplace comes standard with the Dynamic Start Advantage. This new elec-
tronic ignition system is the latest in fireplace technology. It helps to create a better
draft, better flame appearance, less condensation on the glass, and years of care-
free operation. See Page 40 for complete explanation of how the system works.
• Multiple Electronic Pilot Settings
This fireplace uses a gas control valve that is operated by a Multifunction Remote
Control. It can be set up as either an Intermittent Pilot Ignition (IPI) system, or Con-
tinuous Pilot on Demand Ignition (CPI) system (also known as a Pilot on Demand
(POD)).
Model Number Definition
(72-DVTE30P-2 / 72-DVTE30N-2) (-ERG)
72 Number assigned to identify the fireplace
DV Direct Vent
T Top Vent
E Electronic Ignition
30 Natural Gas Input Rating in BTU
N or P Natural Gas or Propane
-2 Revision Number
-ERG Includes Eclipse faceplate and Eternal
Flame reflective ceramic glass panel set
CPI vs IPI:
Continuous Pilot on Demand Ignition (CPI): In this mode the
pilot runs continuously even when the main burner is off. The
Continuous Pilot on Demand Ignition operates on a seven day
cycle. If the main burner is not turned on for seven continuous
days, the pilot will turn itself off. When the main burner is lit
again the cycle repeats. The pilot will remain lit for seven days,
even after the main burner is turned off. If the main burner is lit
during a seven day timing cycle, the seven day timer will reset.
Intermittent Pilot Ignition (IPI): A fuel saving mode in which the
pilot is only used when the main burner is on. This appliance is
shipped in IPI mode. IPI mode is often the preferred method,
however, there are some situations where it may be preferable
to switch the fireplace into CPI mode. For example, in colder
climates the glass door or the front of the fireplace could become
very cold to the touch. Dynamic Start Advantage will solve most
problems experienced by older IPI operated fireplaces.
