TABLE OF CONTENTS
Caution and Safety Instructions
6
Appliance Certification, Installation Codes and Specifications, High Altitude Installation
7
Gas Connections
8
Appliance Dimensions and Clearance to Combustibles
9
Mantle Clearances
10
Framing Dimensions, Termination
11
Locating Gas Fireplace and Vent Termination Locations
12
Allowable Termination Locations
13
Approved Vent Components and Venting Connection
14
Venting
14-24
Electrical Connections (Fan System) and Wiring Diagram
25
Log Placement (Fiber Log Set)
26-30
Brick panel set installation
31-33
Eternal Flame Reflective Ceramic Glass panel set installation
34-35
First Fire and Lighting Instructions (CAUTION)
36
Final Installation Check and Initial Operation
37
Lighting Instructions on Rating Plate
38
Glass Door Removal and If your Glass Breaks
39
Louver (grill) instructions
40
Safety Barrier Installation
41
Eclipse Front
42-43
Dynamic Start Advantage
44
Remote Control Set-up and Operation
45-50
Maintenance and Cleaning the Appliance
51
Servicing Under Warranty & Adjusting Primary Air Shutter
52
Adjusting Primary Air Shutter (Continued) Changing Main Burner Orifice
53
Checking Inlet/Outlet gas pressures, Adjusting Pilot and Convertible Pilot Orifice
54
Replacing Convection Blower (Fan)
55
Valve Tray Assembly and Parts List
56
Log and Pan Burner Parts List
57
Replacement Parts List
58-59
Warranty
60
Frequently Asked Questions
61
Warranty Registration
62
